Product Features:
- Ultra Light Steering
- Internal Battery Charger
- Adjustable Straddle Legs
Specifications
| MODEL | CDD13 |
|---|---|
| Type of operation | Pedestrian |
| Controller | CURTIS |
| Lift motor | 2.2 kW |
| Drive motor | 1.5 kW |
| Overall Height | 2330mm |
| Engine type | Electric |
| Max. Lifting height | 3500mm |
| Battery Voltage/Rated capacity | 24/28 V/Ah |
| Overall width | 1400mm |
| Load Center | 600mm |
| Rated Capacity | 1300kgs |
